Optical Transceivers and Photonic Circuits
Analog, High-Speed, and Diode Laser Integrated Circuit Layout for Optical CommunicationsBy Amara OkonkwoLength13h 9m
About this audiobook
Between the laser and the recovered bit sit a dozen circuits that must all meet budget. This book designs them with you.
An optical transceiver is not one invention but a chain of compromises: a laser that must be biased, modulated and kept cool; a driver that must swing fast without ringing; a photodiode whose every stray picofarad costs sensitivity; a transimpedance amplifier pushed against the transimpedance limit; and a clock recovery loop that must lock onto a signal already blurred by jitter and dispersion. Each stage has its own budget, and a link only closes when every one of them does. This book works through that chain from first principles, with the equations and the practical numbers side by side.
You will begin with the optical link budget and the fibre propagation limits that set the target, then work through laser rate equations to understand chirp, relaxation oscillation and noise, and use that understanding to choose between direct modulation, electroabsorption and Mach-Zehnder drive. On the receive side you will select PIN or avalanche detection, size a shunt-feedback transimpedance amplifier against the transimpedance limit and its input-referred noise, chain limiting stages, cancel offset, and close a clock recovery loop that survives real jitter. Later chapters extend the design to equalisation and four-level signalling, silicon photonic waveguides, couplers and ring modulators, and the layout, shielding, electrostatic discharge and packaging choices that decide whether a transceiver works on the bench and in the field.
What you will learn
• Build and close an optical link budget from transmitter power to receiver sensitivity
• Apply laser rate equations to chirp, relaxation oscillation and noise in diode laser design
• Compare direct modulation, electroabsorption and Mach-Zehnder drive for a given reach and rate
• Design laser and modulator driver circuits that meet speed and integrity targets
• Choose between PIN and avalanche photodetectors and predict their noise contribution
• Size a shunt-feedback transimpedance amplifier against the transimpedance limit
• Chain post-amplifiers, AGC and offset control without losing dynamic range
• Close a clock and data recovery loop that tolerates real jitter
• Extend a link to equalisation, PAM4 and higher data rates
• Lay out, shield, protect and package a transceiver so it works outside simulation
Written for analog and photonics IC engineers and graduate students, the book assumes comfort with small-signal circuit analysis and basic semiconductor device physics, and takes you from the link budget to the packaged module. It is equally suited to engineers moving into optical communications from wireline or RF design, and to graduate students who need the full signal chain in one place rather than scattered across papers.
Audiobook details
GenreTechnology
Length13 hrs 9 mins
Narrated byListen with 1,000+ voices
FormateBook with Audio
Publish dateSep 27, 2026
LanguageEnglish
Table of contents
1Optical Transceivers and Photonic Circuits
2Foreword
3Preface
4About This Book
5Chapter 1: Optical Links and Budgets
Show all chaptersShow less
61.1 Anatomy of an Optical Link and Its Specification Sheet
71.2 Bit Error Rate, Q Factor and the Gaussian Approximation
81.3 Sensitivity, Overload and the Receiver Specification Window
91.4 Power Penalties and the Engineering Margin
101.5 Closing a Link Budget: A Complete Worked Design
111.6 From Budget to Silicon: What the Numbers Demand of the Circuits
12Chapter 2: Fibre Propagation and Bandwidth Limits
132.1 Guiding in Single-Mode and Multimode Fibre
142.2 Chromatic Dispersion and Dispersion Penalty
152.3 Polarisation Mode Dispersion and Fibre Nonlinearity
162.4 Modal Bandwidth and Multimode Reach
172.5 Reach Classes and Technology Selection
18Chapter 3: Semiconductor Laser Physics and Diode Laser Design
193.1 Optical Gain, Carrier Density and Threshold
203.2 Rate Equations, Relaxation Oscillation and Modulation Response
213.3 Linewidth, Chirp and Relative Intensity Noise
223.4 Fabry–Perot, DFB and VCSEL Structures
233.5 Quantum Wells, Temperature Behaviour and Reliability Margins
